KEY FEATURES & ADVANTAGES

100% Oil-Free Operation

• Advanced oil-free lubrication design eliminates hydrogen contamination risks

• Ensures gas purity for protecting downstream catalysts and fuel cells

• Ideal for applications with stringent hydrogen quality requirements

High-Pressure Performance

• Sophisticated three-stage compression technology

• Efficiently elevates hydrogen pressure from 0.6 MPa to 18.0 MPa

• Meets demanding pressure requirements for various applications

Superior Durability

• All gas-wetted components constructed from stainless steel

• Excellent corrosion resistance in hydrogen environments

• Long service life with minimal maintenance requirements

Efficient Operation

• Integrated air-cooling system eliminates need for external cooling water

• Compact W-type structure provides excellent stability and balance

• Space-saving design for easy installation and maintenance

TECHNICAL SPECIFICATIONS

Operating Parameters

• Inlet Temperature: ≤ 40°C

• Discharge Temperature: ≤ 50°C (after cooling)

• Piston Stroke: 75 mm

• Shaft Speed: 200 r/min

• Motor Speed: 730 r/min

Physical Specifications

• Dimensions: 1400 × 1000 × 1200 mm

• Weight: 800 kg

• Connections: G1/2" or M16×1.5

• Structural Style: W-Type, Oil-Free

• Cylinder Quantity: 3

MATERIAL CONSTRUCTION

Gas-Wetted Components:

• Cylinder: Stainless Steel

• Valves: Stainless Steel

• Piping & Cooler: Stainless Steel

APPLICATIONS

Industrial Processes

• Continuous hydrogen pressure for chemical synthesis reactors

• Atmosphere control in steel heat treatment furnaces

• Industrial reactor feed systems

Hydrogen Energy Infrastructure

• Booster compressor in hydrogen refueling stations (HRS)

• Fuel Cell Electric Vehicles (FCEVs) infrastructure

• Hydrogen storage and distribution systems

General Applications

• Any application requiring clean, dry, high-pressure hydrogen gas

• Laboratory and research facilities

• Energy storage systems

CRITICAL OPERATIONAL REQUIREMENTS

⚠️ Mandatory Precautionary Measures:

• Input gas must be dry and free of solid particles

• Moisture or particulate ingress will cause severe compressor damage

• Warranty is void without proper upstream filtration and gas drying

• Required: Appropriate upstream filtration and gas drying equipment

WHY CHOOSE THIS COMPRESSOR?

• ✅ Maximum Purity: 100% oil-free operation ensures contaminant-free hydrogen

• ✅ High-Pressure Capability: Three-stage compression to 18.0 MPa

• ✅ Corrosion Resistant: Full stainless steel construction for hydrogen service

• ✅ Low Maintenance: Robust design with air-cooled simplicity

• ✅ Compact Design: W-type structure saves space while ensuring stability

• ✅ Energy Efficient: Optimized power consumption for cost-effective operation

•
