Key Features

• 100% Oil-Free Design: PTFE-filled rings and packings ensure pure CO₂ output

• Two-Stage Compression: Efficient pressure boost from 0.4 to 3.0 MPa

• Water-Cooled System: Maintains optimal operating temperatures

• Robust Construction: Stainless steel and cast iron components for durability

• Customizable Voltage: Available in 400V/50Hz or other specifications

• High Flow Capacity: 600 Nm³/h for demanding industrial applications

•





• TECHNICAL DATA

• Parameter	Specification	Parameter	Specification
  Medium	CO₂	Quantity	1
  Inlet Pressure	0.4 MPa(G)	Inlet Temperature	0 ~ 40 °C
  Discharge Pressure	3.0 MPa(G)	Discharge Temperature	≤50 °C
  Flow Rate	600 Nm³/h	Piston Stroke	140 mm
  Model	600/6-40	Compression Stages	2
  Structural Style	Vertical Skid Mounted	Cylinder Quantity	4
  Shaft Speed	450 rpm ″	Voltage	400V/50Hz (Customizable)
  Cooling Mode	Water Cooling	Cooling Water Flow	6.5 t/h
  Shaft Power	60 kW	Main Motor Speed	1470 rpm ″
  Main Motor	75 kW, 400 V, 50 Hz ″
  Dimensions	2650×1850×2350 mm ″	Weight	4.3 t ″
  Interface Size	Inlet DN80 / Discharge DN32 Cooling Water DN40
  Drive Mode	Belt Drive
  Main Materials
  – Fuselage, Slide	Cast Iron
  – Piston Ring, Packing	Filled PTFE
  – Air Valve, Cylinder Liner	Stainless Steel

Applications

• Carbon capture and storage (CCS)

• Supercritical fluid extraction

• Enhanced oil recovery

• Food and beverage processing

• Industrial gas processing

Delivery Time: 100 days after order confirmation
